First launched in 1990, the Pacifica Series was driven by the California session scene of the day – where versatility, performance and individuality were key. Inspired by those custom shop guitars and that original vision, Pacifica 600 models represent today’s embodiment of the Pacifica concept.

Seymour Duncan Pickups in Two Configurations

All current Pacifica 600 models feature a TB-14 “Custom 5” humbucker in the bridge position for full tone with a scooped midrange and a coil tap for additional versatility. PAC611 models pair this with an SP90-1 for vintage soapbar tone, and PAC612 models use SSL-1 single-coils in the middle and neck positions for authentic 1950s chime.

Grover Locking Tuners

These tuners offer additional pitch stability by reducing string slippage – especially for guitars equipped with a vibrato bridge – without sacrificing fast string changes.

Graph Tech TUSQ Nut and String Trees

TUSQ XL is precision-engineered to couple the string vibration to the neck bringing out richness and harmonics. The Teflon-impregnated material eliminates string binding and helps to insure tuning stability, even with wide bends.

Graph Tech String Saver Saddles on Hardtail Models

Paired with the original Yamaha steel bridgeplate on Pacifica 611H/HFM models, these self-lubricating saddles reduce string breakage while offering balanced tone and increased sustain.

Wilkinson VS50 6 Vibrato Bridges

Precision-machined zinc saddles are matched with hardened steel and a knife-edge baseplate for a responsive feel and stable tuning.

Specifications:

• Construction: Bolt-On
• Scale Length: 25-1/2" (648 mm)
• Body Materials: Maple/Alder/Flame Maple Laminated
• Body Finish: Gloss Polyurethane
• Neck Materials: Maple
• Neck Finish: Gloss Polyurethane
• Fingerboard Materials: Rosewood
• Fingerboard Radius: 13-3/4" (350 mm)
• Fret Wire: Medium
• Number of Frets: 22
• Nut Materials: Graph Tech TUSQ
• Neck Width @ 0 Fret / 12th Fret: 41/51.4 mm
• Thickness @1st Fret / 12th Fret: 20.9/22.9 mm
• Neck Pickup: Seymour Duncan SSL-1
• Middle Pickup: Seymour Duncan SSL-1 RwRp
• Bridge Pickup: Seymour Duncan TB-14
• Controls: Master Volume, Master Tone (Push-Pull Coil Split)
• Pickup Switch: 5-Position Lever Switch
• Bridge: Wilkinson VS50 6
• Tremolo Arm: Φ5.2(Slot-in)
• String Spacing: 10.8 mm
• Tailpiece: -
• Tuning Machines: Grover Locking Tuners
• Pickguard: 3-Ply Black
• String Gauge: D'Addario EXL120 / 0.009-0.042
• Case: -
• Special Features: -
