Mono-unit output jack

The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.

Edge-Zero II tremolo bridge

The Edge Zero II bridge design features a lower profile tremolo for playing comfort and stud lock function for stable tuning.

Quantum pickups

The Quantum pickups provide accelerated bass response for exceptionally fast tracking of high-speed staccato riffing with crushing mid range and precise high-end articulation.

Wizard III Maple neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability and features a two-octave 24-fret fretboard for a wide tonal range.

Specifications:

• neck type: Wizard III / Maple neck
• top/back/body: Meranti body
• fretboard: Jatoba fretboard / Sharktooth inlay
• fret: Jumbo frets
• number of frets: 24
• bridge: Edge-Zero II bridge
• string space: 10.8mm
• neck pickup: Quantum (H) neck pickup/Passive/Ceramic
• middle pickup: Quantum (S) middle pickup/Passive/Alnico
• bridge pickup: Quantum (H) bridge pickup/Passive/Ceramic
• factory tuning: 1E,2B,3G,4D,5A,6E
• strings: D'Addario® EXL120
• string gauge: .009/.011/.016/.024/.032/.042
• nut: Locking nut
• hardware color: Black

Neck Dimensions:

• Scale: 648mm/25.5"
• a: Width 43mm at NUT
• b: Width 58mm at 24F
• c: Thickness 19mm at 1F
• d: Thickness 21mm at 12F
• Radius: 400mmR
